Lima Locomotive & Machine Co.

Photo Credit:
No Photo At This Time
Shop Number 1873 - Built for: A. Cameron & Co.
{1,312th Lima Built Shay}
Built:
5-9-1907
Class:
A
15-2
Trucks:
2
Cylinders:
[#-Diam x Stroke]
2 - 7 x 12
Gear Ratio:
3.071
Wheel Dia. Dia.:
26"
Gauge:
36"
Boiler:
[Style - Dia.]

ST. - 31.5"
Boiler Pressure:
In Lbs. (PSI)
160
Tractive Effort:
8,334 Lbs.
Factor of
Adhesion:

4.89
Maximum
Safe Speed:

10.1
Fuel Type:
Wood
Fuel Capacity:
0.25 Cords
Water Capacity:
730 Gallons
Empty Weight:
As built
33,700
Owners:
A. Cameron & Co. #2 "A. CAMERON", Vass, NC
Disposition: Scrapped
Additional Notes:
