Lima Locomotive & Machine Co.

Photo Credit:
David Thomas collection (c1925)
Shop Number 2238 - Built for: Three Forks Coal Mining Co.
{1,677th Lima Built Shay}
Built:
10-28-1909
Class:
B
28-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
3 - 8 x 10
Gear Ratio:
3.071
Wheel Dia.:
26.5"
Gauge:
42"
Boiler:
[Style - Dia.]

E.W.T. - 35.375"
Boiler Pressure:
In Lbs. (PSI)
160
Tractive Effort:
13,350 Lbs.
Factor of
Adhesion:

4.69
Maximum
Safe Speed:

10.3
Fuel Type:
Coal
Fuel Capacity:
1.5 Tons
Water Capacity:
850 Gallons
Empty Weight:
As built
51,700
Owners:
Three Forks Coal Mining Co. #3, Vindex, MD
(c1913) [Std.] Chaffee Coal Co., Chaffee RR #3, Vindex, MD
Pittsburgh Equip. Co. (D), Pittsburgh, PA
(c8-1921) J. E. Tartt, Narkeeta, MS
(12-1921) Sucarnochee Lbr. Co. #3, Narkeeta, MS
(1926) Sucarnochee Lbr. Co. #3, Akron (Keysville), MS
Disposition: Scrapped
Additional Notes:
