Lima Locomotive & Machine Co.


Photo Credit:
Both : Max Robbin, P.E. collection
Shop Number 2248 - Built for: Chesapeake & Ohio Ry
{1,687th Lima Built Shay}
Built:
4-26-1910
Class:
D
150-4
Trucks:
4
Cylinders:
[#-Dia. x Stroke]
3 - 17 x 18
Gear Ratio:
2.05
Wheel Dia.:
46"
Gauge:
std.
Boiler:
[Style - Dia.]

E.W.T. - 62.375"
Boiler Pressure:
In Lbs. (PSI)
200
Tractive Effort:
52,161 Lbs.
Factor of
Adhesion:

5.98
Maximum
Safe Speed:

26.7
Fuel Type:
Coal
Fuel Capacity:
9 Tons
Water Capacity:
8,000 Gallons
Empty Weight:
As built
242,000
Owners:
Chesapeake & Ohio RY Co., Chesapeake & Ohio RY #11 (3rd), Huntington, WV
(12-1923) West Virginia Pulp & Paper Co., Greenbrier, Cheat & Elk RR #14, Cass, WV
(10-1928) West Virginia Pulp & Paper Co. #14, Cass, WV
(6-1932) Western Maryland RY Co., Western Maryland RY #5, Elkins, WV
(5-1945) Western Maryland RY Co., Western Maryland RY #5, Vindex, MD
(9-1950) Stored at Vindex, MD
(after 1950) Stored Maryland Junction, WV
Disposition: (10-1954) Scrapped at Hagerstown, MD
Additional Notes: Shipped to Huntington, WV
(12-1923) Bought as scrap, (2-1924) arrived at Cass and under repair until 9-1924
