Lima Locomotive & Machine Co.

Photo Credit: Brad Hovik collection
Shop Number 2266 - Built for: Ebey Logging Co.
{1,705th Lima Built Shay}
Built:
1-18-1910
Class:
B
60-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
3 - 12 x 12
Gear Ratio:
2.211
Wheel Dia.:
36"
Gauge:
std.
Boiler:
[Style - Dia.]

E.W.T. - 46.375"
Boiler Pressure:
In Lbs. (PSI)
200
Tractive Effort:
23,868 Lbs.
Factor of
Adhesion:

5.29
Maximum
Safe Speed:

19.4
Fuel Type:
Coal
Fuel Capacity:
3.75 Tons
Water Capacity:
2,000 Gallons
Empty Weight:
As built
100,900
Owners:
Hofius Steel & Equip. Co., Seattle, WA
Ebey Log. Co., Marysville & Arlington RY #4, Arlington, WA
(1915) Ebey Log. Co. (Marysville & Arlington RR, #4), Arlington, WA
(1927) H. J. Armstrong Co. (D), Seattle, WA
(4-13-1928) Sauk River Lbr. Co. #2 (1st), Darrington, WA
Disposition: (11-25-1939) Scrapped
Additional Notes: The Marysville & Arlington RY Co. became the Marysville & Arlington RR Co. in 1915, however the operating railroad was always Marysville & Arlington RY.
