Lima Locomotive & Machine Co.

Photo Credit:
No Photo At This Time
Shop Number 2367 - Built for: Chapman Tbr. Co.
{1,806th Lima Built Shay}
Built:
11-18-1910
Class:
C
70-3
Trucks:
3
Cylinders:
[#-Dia. x Stroke]
3 - 12 x 15
Gear Ratio:
2.25
Wheel Dia.:
36"
Gauge:
std.
Boiler:
[Style - Dia.]

W.T. - 50"
Boiler Pressure:
In Lbs. (PSI)
200
Tractive Effort:
30,375 Lbs.
Factor of
Adhesion:

5.13
Maximum
Safe Speed:

19.0
Fuel Type:
Oil
Fuel Capacity:
1,200 Gals.
Water Capacity:
3,000 Gallons
Empty Weight:
As built
129,300
Owners:
Hofius Steel & Equip. Co. (D), Seattle, WA
Chapman Tbr. Co. (Fir Tree Lbr. Co), Portland & Southwestern RR #5, Scappoose, OR
(2-1913) Nehalem Tbr. & Log. Co. #5 (2nd), Scappoose, OR
(1926) Clark & Wilson Lbr. Co. #5 (2nd), Scappoose, OR
(1930) Clark & Wilson Lbr. Co., #5, Wilark, OR
Disposition: Scrapped
Additional Notes:
