Lima Locomotive Works, Inc.

Photo Credit:
George R. Kadelak collection (BP 6-1923)
Shop Number 3225 - Built for: National Lbr. & Mfg. Co.
{2,642nd Lima Built Shay}
Built:
6-26-1923
Class:
C
70-3
Trucks:
3
Cylinders:
[#-Dia. x Stroke]
3 - 12 x 15
Gear Ratio:
2.25
Wheel Dia.:
36"
Gauge:
std.
Boiler:
[Style - Dia.]
E.W.T. - 50.125"
Boiler Pressure:
In Lbs. (PSI)
200
Tractive Effort:
30,376 Lbs.
Factor of
Adhesion:
5.61
Maximum
Safe Speed:
19.0
Fuel Type:
Oil
Fuel Capacity:
1,200 Gals.
Water Capacity:
3,000 Gallons
Empty Weight:
As built
143,000
Owners:
National Lbr. & Mfg. Co. #4, Cedarville, WA
(1927) Schafer Brothers Log. Co. #11 later #21, Brady, WA
Disposition: Scrapped
Additional Notes:
Photo: Schafer Brothers Logging Company 3-truck Shay locomotive number 11
