Lima Locomotive & Machine Co.

Photo Credit:
Gary P. Price collection (c1905)
Shop Number 960 - Built for: Marion & Rye Valley RY Co.
{902nd Lima Built Shay}
Built:
11-25-1904
Class:
B
55-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
3 - 12 x 12
Gear Ratio:
2.21
Wheel Dia.:
36"
Gauge:
std.
Boiler:
[Style - Dia.]
W.T. - 46"
Boiler Pressure:
In Lbs. (PSI)
180
 Tractive Effort:
21,481 Lbs.
 Factor of
Adhesion:
5.76
 Maximum
Safe Speed:
19.4
Fuel Type:
Coal
Fuel Capacity:
3.8 Tons
Water Capacity:
2,000 Gallons
Empty Weight:
As built
97,500
Owners:
Marion & Rye Valley RY, Marion & Rye Valley RY #8, Marion, VA
(1905) Marion & Rye Valley RR, Marion & Rye Valley RR #8, Marion, VA
(c1906) Loaned to; Fairwood Lbr. Co., Fairwood, VA
Raleigh Lbr. Co. (W. M. Ritter Lbr. Co.), Raleigh & Southwestern RY #2 (1st), Glen Morgan, WV
Disposition: (by 10-1928) Scrapped
Additional Notes: (10-1928) boiler put on sn-960
